Container Specifications

General Purpose Containers (GP)

20' Standard Dry Container

Exterior Dimensions (foot)	Length	Width	Height
	20'	8'	8' 6''
Interior Dimensions (mm)	Length	Width	Height
	5,882 - 5,898	2,332 - 2,353	2,387 - 2,396
Door Openings (mm)		Width	Height
		2,332 - 2,343	2,261 - 2,288
Weights (kg)	Gross	Tare	Payload
	24,000 / 30,480 *	2,220 - 2,350 *	21,660 - 28,260 *
Volume (m³)			33.0 - 33.2

20' 40' Standard Dry Container

Exterior Dimensions (foot)	Length	Width	Height
	40'	8'	8' 6''
Interior Dimensions (mm)	Length	Width	Height
	12,022 - 12,039	2,332 - 2,362	2,385 - 2,399
Door Openings (mm)		Width	Height
		2,333 - 2,341	2,260 - 2,284
Weights (kg)	Gross	Tare	Payload
	30,480 / 32,500	3,660 - 4,020	26,460 - 28,840
Volume (m³)			67.2 - 67.8

40' High Cube Dry Container

Exterior Dimensions (foot)	Length	Width	Height
	40'	8'	9' 6'
Interior Dimensions (mm)	Length	Width	Height
	12,031 - 12,039	2,350 - 2,362	2,667 - 2,700
Door Openings (mm)		Width	Height
		2,336 - 2,343	2,580 - 2,591
Weights (kg)	Gross	Tare	Payload
	30,480 / 32,500	3,820 - 4,200	26,280 - 28,640
Volume (m³)			75.7 - 76.7

Special Containers

20' Open Top Special Container

Exterior Dimensions (foot)	Length	Width	Height
	20'	8'	8' 6''
Interior Dimensions (mm)	Length	Width	Height
	5,890 - 5,910	2,337 - 2,352	2,340 - 2,388
Door Openings (mm)		Width	Height
		2,320 - 2,342	2,273 - 2,305
Weights (kg)	Gross	Tare	Payload
	30,480	2,230 - 2,680	27,800 - 28,250
Volume (m³)			31.9 - 32.8

20' Flat Rack Special Container

Exterior Dimensions (foot)	Length	Width	Height
	20'	8'	8' 6''
Interior Dimensions (mm)	Length	Width	Height
	6,058	2,438	2,219 - 2,234
Door Openings (mm)		Width	Height
		-	-
Weights (kg)	Gross	Tare	Payload
	30,000 / 40,000	2,600 - 2,960	27,400 - 37,040

40' Open Top Special Container

Exterior Dimensions (foot)	Length	Width	Height
	40'	8'	8' 6''
Interior Dimensions (mm)	Length	Width	Height
	12,034 - 12,050	2,348 - 2,352	2,331 - 2,352
Door Openings (mm)		Width	Height
		2,337 - 2,342	2,273 - 2,340
Weights (kg)	Gross	Tare	Payload
	30,480	3,720 - 4,250	26,230 - 26,760
Volume (m³)			31.9 - 32.8

40' Open Top High Cube Special Container

Exterior Dimensions (foot)	Length	Width	Height
	40'	8'	9' 6''
Interior Dimensions (mm)	Length	Width	Height
	12,032	2,352	2,655
Door Openings (mm)		Width	Height
		2,340	2,585
Weights (kg)	Gross	Tare	Payload
	30,480 / 32,500	4,300 - 4,400	26,180 - 28,200
Volume (m³)			75.1

40' Flat Rack Special Container

Exterior Dimensions (foot)	Length	Width	Height
	40'	8'	8' 6''
Interior Dimensions (mm)	Length	Width	Height
	12,182	2,438	1,978
Door Openings (mm)		Width	Height
		-	-
Weights (kg)	Gross	Tare	Payload
	45,000	5,180	39,820

20' Standard Reefer Container

Exterior Dimensions (foot)	Length	Width	Height
	20'	8'	8' 6''
Interior Dimensions (mm)	Length	Width	Height
	5,558	2,300	2,324
Door Openings (mm)		Width	Height
		2,296	2,290
Weights (kg)	Gross	Tare	Payload
	30,480*	2,500 - 3,050*	27,100 - 27,980*
Volume (m³)			30.00

40' High Cube Reefer Container

Exterior Dimensions (foot)	Length	Width	Height
	40'	8'	9' 6''
Interior Dimensions (mm)	Length	Width	Height
	11,582 - 11,651	2,296 - 2,310	2,552 - 2,607
Door Openings (mm)		Width	Height
		2,288 - 2,310	2,490 - 2,576
Weights (kg)	Gross	Tare	Payload
	34,800	4,260 - 4,900	29,900 - 30,540
Volume (m³)			67.5 / 70
